One of Himiway’s best-known fat-tire e-bikes: a 750W motor, a 960 Wh battery with up to 80 miles of range, and a 400 lb payload capacity.
26 x 4.0 Kenda tires and a lockout suspension fork handle sand, snow and gravel.
Top speed: 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows.
Highlights
- 750W brushless geared hub motor (86Nm torque)
- 48V 20Ah Samsung/LG battery (960Wh)
- Up to 80-mile riding range
- 26" x 4.0" Kenda fat tires for all-terrain use
- 95mm travel front suspension fork with lockout
- Torque sensor for natural pedal assistance
- Shimano Altus 7-speed drivetrain
- Hydraulic disc brakes (Tektro HD-E3520)
Specifications
| Frame | 6061 Aluminum frame |
|---|---|
| Headset | Neco H156EM 28.6 44-56 30 |
| Fork | TRAMA 26- FAT34-26-HLO 95mm travel |
| Front Wheel | MD-147 26×4.0, stainless spokes, MB015-92 hub |
| Rear Wheel | 26×4.0, 48V 750W hub motor |
| Tires | Kenda 26 x 4.0 |
| Battery | Samsung/LG 48V 20Ah (960Wh) |
| Motor | 750W brushless geared hub motor |
| Display | LCD display with USB charging |
| Throttle | Thumb throttle |
| Sensors | Torque, speed, brake sensors |
| Crankset | 170mm crank arm, 44T chainring |
| Freewheel | Shimano MF-TZ500-7 14-28T |
| Chain | KMC Z8.3 EPT 120L |
| Groupset | Shimano Altus 7-speed |
| Front Brake | Tektro HD-E3520 hydraulic disc |
| Rear Brake | Tektro HD-E3520 hydraulic disc |
| Rotors | 180mm front / rear |
| Stem | Zoom alloy stem |
| Handlebar | Promax alloy handlebar |
| Saddle | Himiway comfort saddle |
| Pedal | Aluminum pedals |
| Lights | 48V LED lighting system |
| Kickstand | Heavy-duty aluminum kickstand |
| Range | Up to 80 miles |
| Max Payload Capacity | 400 lb |
| Rider Height | 5’3" – 6’5" |
| Top Speed | 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows |
| Warranty | 2-year Skyline Volt warranty |
Delivery, returns and warranty
- Free shipping to the lower 48 states. Orders leave our warehouse in 0-1 business days and arrive in 2-5 business days.
- Ships by freight, mostly assembled, with tools and setup guide included.
- 14-day returns with a free return label. Items must be new and unused in original packaging.
- Every order is covered by the 2-year Skyline Volt warranty.
