The D5 2.0 on 20-inch wheels: easier to handle and a great fit for shorter riders, with the same 750W motor and full suspension.
Up to 70 miles of pedal-assist range and an optional second battery.
Top speed: 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows.
Highlights
- 750W rear hub motor (1300W peak power)
- 48V 15Ah lithium battery
- 90Nm torque output
- 20-inch compact wheel design
- Full suspension system (90mm front / 100mm rear travel)
- 20×4.0 fat tires for all-terrain stability
- Step-through aluminum frame
- Tektro hydraulic disc brakes
Specifications
| Frame | Aluminum alloy step-through frame |
|---|---|
| Motor | 750W rear hub motor (1300W peak) |
| Battery | 48V 15Ah lithium battery |
| Torque | 90Nm |
| Tire Size | 20 x 4.0 fat tires |
| Suspension | Front 90mm / Rear 100mm travel |
| Brake System | Tektro hydraulic disc brakes |
| Drivetrain | Shimano 8-speed |
| Display | 3.5- LCD smart display |
| Sensor | Torque / cadence switchable |
| Range | Up to 70 miles (PAS) |
| Load Capacity | Up to 440 lbs |
| Charging | 48V fast charger (3.0A) |
| Weight | ~80 lbs |
| Top Speed | 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows |
| Warranty | 2-year Skyline Volt warranty |
Delivery, returns and warranty
- Free shipping to the lower 48 states. Orders leave our warehouse in 0-1 business days and arrive in 2-5 business days.
- Ships by freight, mostly assembled, with tools and setup guide included.
- 14-day returns with a free return label. Items must be new and unused in original packaging.
- Every order is covered by the 2-year Skyline Volt warranty.
