Moto-inspired styling with a long comfort saddle, full suspension and 20 x 4 fat tires. It turns heads and rides as smoothly as it looks.
A 960 Wh Samsung/LG battery gives up to 80 miles of range.
Top speed: 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows.
Highlights
- 750W brushless geared hub motor with 86Nm torque
- Samsung/LG 48V 20Ah battery
- Up to an 80-mile riding range
- 20" x 4" Kenda fat tires for all-terrain riding
- Aerospace-grade 6061 aluminum frame
- Extended comfort saddle
- Hydraulic braking system
- Torque, speed, and brake sensors
Specifications
| Frame | 6061 Aluminum frame |
|---|---|
| Headset | Neco H114 28.6 44 30 |
| Fork | KKE R150S coil spring fork compression | Rebound adjustable 140mm travel 15150mm axle |
| Shock | EXA A5-RE 18047mm |
| Front Wheel | Rim: MD-147 20 4.0" 36H 12G A/V | Spoke: 12G 171mm/173mm | Hub: MB016F-92-T 15 135MM 12G36H |
| Rear Wheel | Rim: MD-147 204.0" 36H 12G A/V | Spoke: 12G 126mm/127mm Hub: 48v 750w | Himiway Hub Motor |
| Tires | Kenda X Himiway 204.0 |
| Battery | Samsung/LG 48V 20Ah |
| Motor | 750W brushless gear motor |
| Display | Himiway C2 LCD Display |
| Throttle | Thumb throttle |
| Sensors | Torque sensor丨speed sensor丨brake sensor |
| Crankset | 44T BCD104 6061-T6 145mm |
| Freewheel | Shimano MF-TZ500-7 14-28T |
| Chain | KMC Z8.3 EPT 130L |
| Groupset | Shimano altus M310 7 speed |
| Front Brake | Tektro HD-E3520 hydraulic brake |
| Rear Brake | Tektro HD-E3520 hydraulic brake |
| Rotors | Tektro TR180-52 F:180mm R:180mm |
| Stem | 3D forged alloy Ext:40mm |
| Handlebar | YC-B086 22.2 31.8 720mm |
| Seatpost | / |
| Saddle | Extended seat |
| Pedal | Aluminum pedal |
| Lights | 48V LED light |
| Kickstand | Heavy-duty aluminum kickstand |
| Range | 60-80 miles |
| Controller | 48V/22A |
| Charger | U.S. standard 3.0 A fast charger |
| Rider Height | 5’4"~6’3" |
| Weight | 88 lb. |
| Max. Payload Capacity | 330 lb. |
| Top Speed | 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows |
| Warranty | 2-year Skyline Volt warranty |
Delivery, returns and warranty
- Free shipping to the lower 48 states. Orders leave our warehouse in 0-1 business days and arrive in 2-5 business days.
- Ships by freight, mostly assembled, with tools and setup guide included.
- 14-day returns with a free return label. Items must be new and unused in original packaging.
- Every order is covered by the 2-year Skyline Volt warranty.
