A folding commuter that fits under a desk or in a car trunk, with a torque sensor for smooth, natural assistance.
An LG 21700 IP65 battery gives up to 70 miles of range per charge.
Top speed: 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows.
Highlights
- 500W brushless geared hub motor
- 48V 15Ah LG 21700 IP65 battery
- Up to 70-mile riding range
- 2-step foldable frame design
- Torque, speed, and brake sensors
- 20" x 2.4" commuter tires
- Front suspension fork with 40mm travel
- Shimano Altus 7-speed drivetrain
Specifications
| Frame | Front: 6061 aluminum Rear:A356 Steel |
|---|---|
| Headset | Neco H510 |
| Fork | Coil suspention fork, 40mm travel, is disc mount |
| Front wheel | Rim: MD-260 20 2.5" 36H 13G A/V | Spoke: 13G 171MM/172MM | Hub: MS-37F 13G 36H 100mm |
| Rear wheel | Rim: MD-260 20 2.5" 36H 13G A/V | Spoke: 13G 133MM/134MM | Hub: 48v 500w Himiway Hub Motor |
| Tires | Innova 20×2.40 IA-1283 |
| Battery | 48V15AH LG 21700 IP65 720Wh |
| Motor | 500w Himiway brushless gear motor |
| Display | Himiway LCD Display |
| Throttle | Thumb throttle |
| Sensors | Torque sensor丨speed sensor丨brake sensor |
| Crankset | Crank arm:6061-T6 145mm | Chain ring: 44T narrow wide steel chainring BCD104 |
| Cassette | Shimano MF-TZ500-7 14-28T |
| Chain | KMC Z8.3 EPT 100L |
| Groupset | Shimano altus M310 7 speed |
| Front brake | Nutt JAK-8 mechanical disc brake |
| Rear brake | Nutt JAK-8 mechanical disc brake |
| Rotors | F:160mm R:160mm |
| Stem | Folding stem, riser length: 360mm |
| Handlebar | JY-A153 W:600 |
| Seatpost | Himiway flip seatpost 27.2300 |
| Saddle | Himiway TTZ032X |
| Pedal | Aluminum pedal |
| Lights | 48V LED light |
| Kickstand | Aluminum kickstand |
| Range | 70 miles |
| Controller | 48V/18A |
| Charger | US standard 2.0 A smart charger |
| Rider height | 5’~6′ |
| Weight | 60.6 lb. |
| Max payload capacity | 300 lb. |
| Top Speed | 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows |
| Warranty | 2-year Skyline Volt warranty |
