A premium full-suspension commuter with a 500W mid-drive and torque sensor. Potholes, curbs and rough pavement barely register.
Schwalbe tires, a dropper seatpost, Shimano hydraulic brakes and an integrated ABUS rear-wheel lock.
Top speed: Up to 28 mph (Class 3).
Highlights
- 500W ANANDA M100 mid-drive motor
- 48V 15Ah Samsung/LG removable battery
- Up to 50-mile riding range
- Full suspension system (front fork + rear shock)
- Torque sensor for natural pedal assistance
- Shimano Altus 9-speed drivetrain
- Hydraulic disc brakes (Shimano MT200)
- 27.5" Schwalbe Super Moto-X tires
Specifications
| Frame | 6061 Aluminum frame |
|---|---|
| Headset | TOPYCWZ-5662-01 52 52 39.8 |
| Fork | SR SUNTOUR X1-BOOST 120mm travel |
| Shock | DNM AO-06 16538mm |
| Front Wheel | 27.5" DM-350 rim, stainless spokes, DM41SB-B15 hub |
| Rear Wheel | 27.5" DM-350 rim, stainless spokes, M102R-148 hub |
| Tires | Schwalbe Super Moto-X 27.5 x 2.4 |
| Battery | Samsung/LG 48V 15Ah (720Wh) |
| Motor | ANANDA M100 500W mid-drive motor |
| Display | BIGSTONE M300C-TFT |
| Throttle | Thumb throttle |
| Sensors | Torque sensor, speed sensor, brake sensor, shifting sensor |
| Crankset | PROWHEEL 44T 170mm BCD104 |
| Cassette | Shimano CS-HG201-9 11-34T |
| Chain | KMC E9 120L |
| Groupset | Shimano Altus M3100 9-speed |
| Front Brake | Shimano MT200 hydraulic disc |
| Rear Brake | Shimano MT200 hydraulic disc |
| Rotors | Shimano RT26 180mm front/rear |
| Handlebar | MTB AL-325BT 680mm |
| Seatpost | Dropper seatpost 31.6mm, 100mm travel |
| Saddle | DDK 153MF |
| Pedal | Aluminum pedals |
| Lights | 48V integrated LED lighting |
| Kickstand | Heavy-duty aluminum kickstand |
| Range | 35-50 miles |
| Controller | 48V/22A |
| Charger | 2.0A US standard smart charger |
| Rider Height | 5’3" – 6’5" |
| Weight | 77 lb |
| Max Payload Capacity | 300 lb |
| Top Speed | Up to 28 mph (Class 3) |
| Warranty | 2-year Skyline Volt warranty |
Delivery, returns and warranty
- Free shipping to the lower 48 states. Orders leave our warehouse in 0-1 business days and arrive in 2-5 business days.
- Ships by freight, mostly assembled, with tools and setup guide included.
- 14-day returns with a free return label. Items must be new and unused in original packaging.
- Every order is covered by the 2-year Skyline Volt warranty.
