A clean, lightweight commuter with an integrated frame and a torque sensor that makes stop-and-go city riding smooth.
Up to 70 miles of range, hydraulic brakes and Shimano 7-speed gearing.
Top speed: 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows.
Highlights
- 500W brushless geared hub motor
- 48V 15Ah Samsung/LG removable battery
- Up to 70-mile riding range
- Advanced torque sensor system
- Lightweight urban commuter frame
- Shimano Altus M310 7-speed drivetrain
- Hydraulic disc brakes
- Integrated LED lighting
Specifications
| Frame | Front: 6061 aluminum Rear:A356 Steel |
|---|---|
| Headset | Neco A16M 44 44 30 |
| Fork | 6061 aluminum 10012mm thru axle, rack mounts, fender mounts, post disc mount |
| Front wheel | Rim: 26"" 1.75 36H 13G A/V | Spoke: 13G 257.5MM/259.5MM | Hub: R303F-12 12g 36H 12 100mm |
| Rear wheel | Rim: 26"" 1.75 36H 13G A/V | Spoke: 13G 225.5MM/226.5MM | Hub: 48v 500w Himiway Hub Motor |
| Tires | Innova IA-2128 262.2 25-60PSI |
| Battery | 48V15AH LG 21700 IP65 720Wh |
| Motor | 500w Himiway brushless gear motor |
| Display | Himiway LED Display |
| Throttle | Thumb throttle |
| Sensors | Torque sensor丨speed sensor丨brake sensor |
| Crankset | Crank arm:J6061-T6 170mm | Chain ring: 38T narrow wide steel chainring BCD104 |
| Freewheel | Shimano MF-TZ500-7 14-28T |
| Chain | KMC Z8.3 EPT 112L |
| Groupset | Shimano altus M310 7 speed |
| Front brake | Tektro HD-E3520 hydraulic brake |
| Rear brake | Tektro HD-E3520 hydraulic brake |
| Rotors | F:160mm R:160mm |
| Handlebar | Himiway integrated handlebar-Stem 680mm width90mm stem |
| Seatpost | Himiway flip seatpost 27.2300 |
| Saddle | TTZ032X |
| Pedal | Aluminum pedal |
| Lights | 48V LED light |
| Kickstand | Adjustable aluminum kickstand |
| Range | 70 miles |
| Controller | 48V/18A |
| Charger | US standard 2.0 A smart charger |
| Rider height | 5’1"~6′ |
| Weight | 68.3 lb. |
| Max payload capacity | 300 lb. |
| Top Speed | 20 mph out of the box (Class 2), switchable to 28 mph (Class 3) where local law allows |
| Warranty | 2-year Skyline Volt warranty |
Delivery, returns and warranty
- Free shipping to the lower 48 states. Orders leave our warehouse in 0-1 business days and arrive in 2-5 business days.
- Ships by freight, mostly assembled, with tools and setup guide included.
- 14-day returns with a free return label. Items must be new and unused in original packaging.
- Every order is covered by the 2-year Skyline Volt warranty.
